Spare Parts >GYQL2020K00-G25

Spare Parts

GYQL2020K00-G25 EDP:10500668

Product Information

The actual product may differ from the displayed image.
For details, please check the dimensions below.

Type   [Outspread ]

Type   [Outspread ]

Diameter (Unit)
Metric Inch
mm in
microns * microinches *
N lbf
deg deg
MPa psi
N/m lbf/in
Nm lbf-in
kg lbs
rpm rpm

* Only ADJAR,ADJRR
Sales unit 1
Hand L
Stock
Unit of Length I
CUTDIA 1.969
B .787
LF 4.921
LH 1.811
CDX .984
WF .801
H .787
HF .787
HBH .157
CW .157
2D Model (DXF)
CAD data name Download
GYQL2020K00-G25
CAD
