Indexable End Mills

SRF


SRFH12S16M

Product Information

  • S-shaped cutting edge provides sharpness similar to that of solid ball nose end mills.
  • Highly accurate corner radius tolerance allows for high precision finishing.

The actual product may differ from the displayed image.
For details, please check the dimensions below.

Type   [Expand ]

Type   [Expand ]

Diameter (Unit)
Metric Inch
mm in
microns * microinches *
N lbf
deg deg
MPa psi
N/m lbf/in
Nm lbf-in
kg lbs
rpm rpm

* Only ADJAR,ADJRR
Hand R
Stock
Unit of Length M
DC 12
DCON 16
BD 11.5
B2 2°36'
B5 1°30'
LF 120
LH 50
LU 15
Cutting item count: CICT 1
Peripheral effective cutting edge count: ZEFP 2
