Fresa de face >BXD4000 >BXD4000R08005CB

Fresa de face

BXD4000
（USINAGEM DE LIGA DE ALUMĺNIO À MATERIAIS DE DIFĺCIL USINABILIDADE）

BXD4000R08005CB

Product Information

  • Mecanismo Anti-Fly do inserto permite fresamento high speed.
  • Inserto de baixo esforço de corte e corpo de alta rigidez.
  • Refrigeração interna.

The actual product may differ from the displayed image.
For details, please check the dimensions below.

Type   [Expand ]

Type   [Expand ]

Diameter (Unit)
Metric Inch
mm in
microns * microinches *
N lbf
deg deg
MPa psi
N/m lbf/in
Nm lbf-in
kg lbs
rpm rpm

* Only ADJAR,ADJRR
Hand R
Stock
Unit of Length M
DC 80
DCON 25.4
DCSFMS 60
DAH 13
DCCB 20
KAPR 90°
RMPX 3
L8 6
LF 50
CBDP 26
KWW 9.5
APMX 15
GAMP +15°
GAMF +15°
WT 1.1
Peripheral effective cutting edge count: ZEFP 5
RPMX 19000
Show more

Stock

:Inventory maintained in Japan.
:Non stock, produced to order only.
:Inventory maintained in Japan. To be replaced by new products.
:-

  • Recommended Cutting Condition

  • Insert for Rotating Tools

  • Spare Parts
