Indexable End Mills >APX4000 >APX4000R352SA32ELA

Indexable End Mills

APX4000


APX4000R352SA32ELA

Product Information

  • Max.depth of cut 15mm.
  • High accuracy, high quality vertical wall.
  • Air coolant through.

The actual product may differ from the displayed image.
For details, please check the dimensions below.

Type   [Expand ]

Type   [Expand ]

Diameter (Unit)
Metric Inch
mm in
microns * microinches *
N lbf
deg deg
MPa psi
N/m lbf/in
Nm lbf-in
kg lbs
rpm rpm

* Only ADJAR,ADJRR
Hand R
Stock
Unit of Length M
DC 35
DCON 32
KAPR 90°
RMPX 6
LF 260
LH 45
APMX 15
GAMP +17°
GAMF +23°
Cutting item count: CICT 2
Peripheral effective cutting edge count: ZEFP 2
RPMX 15400
Show more

Stock

:Inventory maintained in Japan.
:Non stock, produced to order only.
:Inventory maintained in Japan. To be replaced by new products.
:-

  • Recommended Cutting Condition

  • Insert for Rotating Tools

  • Spare Parts
