Solid End Mills >VFR2XLB >VFR2XLBR0010N010
VFR2XLB
(Ball nose, 2 Flute, Long neck)
The actual product may differ from the displayed image.
For details, please check the dimensions below.
Diameter (Unit) | |
---|---|
Stock | ![]() |
Unit of Length | M |
DC | 0.2 |
DCON | 4 |
DN | 0.18 |
B2 | 10.9° |
BHTA2 | 12° |
LF | 50 |
LU | 1 |
APMX | 0.15 |
FHA | 30° |
RE | 0.1 |
Peripheral effective cutting edge count: ZEFP | 2 |
R Tolerance - | -0.005 |
R Tolerance + | 0.005 |
Coated | VFR |
Stock
:Inventory maintained in Japan.
:Non stock, produced to order only.
:Inventory maintained in Japan. To be replaced by new products.
:-
Recommended Cutting Condition
