Linha GY para torneamento de canais

GYH00D
（Tipo 00°）

4Q1R4G24

Product Information

  • Excelente economia com suporte multifuncional
  • Fixação de inserto altamente confiável.
  • Insertos precisos com longa vida útil para aplicação em diversas operações.
  • Inovador sistema Tri Lock.
  • As dimensões mostradas são válidas quando é usado o inserto de referência.

The actual product may differ from the displayed image.
For details, please check the dimensions below.

Type   [Outspread ]

Type   [Outspread ]

Diameter (Unit)
Metric Inch
mm in
microns * microinches *
N lbf
deg deg
MPa psi
N/m lbf/in
Nm lbf-in
kg lbs
rpm rpm

* Only ADJAR,ADJRR
Hand R
Stock
Unit of Length M
DAXN 85
CUTDIA 125
B 25
L4 68
LF 181
LH 50
CDX 25
WF 28
H 32
HF 32
CW 4
Peripheral effective cutting edge count: ZEFP 1
body GYHR3225P00-M25R
Modular Blade GYM25RD-G25-085

Stock

:Inventory maintained.
:Non stock, produced to order only.
:Inventory maintained. To be replaced by new products.
:Inventory maintained in Japan.

  • Recommended Cutting Condition

  • Turning Insert
